Key Features
- Multi-DOF excitation
- Road spectrum reproduction
- Energy recovery
Main Usage
- Vehicle road environment simulation and durability test
Applications
- Vehicle Durability
- Chassis Structure Optimization
Introduction
The SY70W wheel-coupled road simulation system combines servo-hydraulic technology and a high-precision MIMO controller to reproduce real road loads in laboratory conditions for durability, comfort, and NVH validation.
Technical Support
For specs, selection, and quotes:
Series Comparison
| Parameter | SY70W-20 | SY70W-30 | SY70W-40 | SY70W-50 | SY70W-100 | SY70W-200 | SY70W-300 |
|---|---|---|---|---|---|---|---|
| Model | SY70W-20 | SY70W-30 | SY70W-40 | SY70W-50 | SY70W-100 | SY70W-200 | SY70W-300 |
| Max Load | 2000 kg | 3000 kg | 4000 kg | 5000 kg | 10000 kg | 20000 kg | 30000 kg |
| Acceleration Range | 0 — 195 m/s² | 0 — 200 m/s² | 0 — 245 m/s² | 0 — 210 m/s² | 0 — 290 m/s² | 0 — 200 m/s² | 0 — 250 m/s² |
| Applicable Vehicle | Small cars and motorcycles | Small cars | Large cars | Light trucks | Medium trucks | Heavy trucks | Heavy trucks |
| Working Pressure | 21 MPa | 21 MPa | 21 MPa | 21 MPa | 21 MPa | 21 MPa | 21 MPa |
| Pan Diameter | 650 mm | 450 mm | 450 mm | 450 mm | 650 mm | 650 mm | 650 mm |
As our products are continuously optimized, some product information may change. Please stay in contact with us. All rights of interpretation are reserved by Dongling.
